SPEEDYBEE 35A Mini 4IN1 ESC 3-6S 8bit 20x20mm

  • RM155.00 MYR



SPEEDYBEE 35A Mini 4IN1 ESC 3-6S 8bit 20x20mm

Streamline your drone’s performance with the SpeedyBee 35A 4-in-1 ESC, designed for a compact 20x20mm mounting system. This ESC runs on the efficient BLHeli_S JH40 firmware and supports a robust continuous current of 35A across four channels, with the capability to burst up to 45A for those critical high-thrust moments. Optimized for DSHOT300/600 protocols and supporting a wide power input range from 3-6S LiPo, it ensures a seamless power supply with VBAT output. A precise current sensor keeps your flight data accurate, all within a remarkably slim 35 x 35 x 5.5mm footprint and a feather-light weight of just 7g, making it an essential component for any high-performance, lightweight drone build.


Specifications

  • Firmware: BLHeli_S JH40
  • Continuous Current: 35A * 4
  • Burst Current: 45A (5 seconds)
  • ESC Protocol: DSHOT300/600
  • Power Input: 3-6S LiPo
  • Power Output: VBAT
  • Current Sensor: Supported (Scale=250 Offset=-500)
  • Mounting: 20 x 20mm, 3.6mm hole diameter
  • Dimensions: 35 x 35 x 5.5mm
  • Weight: 7g



Includes

  • 1x SpeedyBee 35A 4in1 ESC 20x20mm
